Juniper EX4100-48MP switch L3 48 cổng Multigigabit PoE++ 90W Mist AI

EX4100-48MP

16x 100 MB/1GbE/2.5GbE + 32x 10 MB/100 MB/1GbE

0

48

740 W/1620 W

4

4

920 W AC

AFO (front-to-back airflow)

Cấu hình cổng truy nhập

16x 100 MB/1GbE/2.5GbE + 32x 10 MB/100 MB/1GbE

PoE/PoE +Ports

0

Số cổng PoE++

48

Ngân sách PoE (1/2 PSU)

740 W/1620 W

Cổng 10GbE

4

Cổng 25GbE

4

Công suất bộ nguồn

920 W AC

Làm mát

AFO (front-to-back airflow)

Công suất bộ nguồn

920 W AC AFO

Acoustics Noise (dBA) – Typical (1 PSU)

36.8

Acoustics Noise (dBA) – Maximum (2 PSU)

54.3

Backplane / Virtual Chassis

200 Gbps Virtual Chassis interconnect to combine up to 10 units as a single logical device

Lưu lượng gió tối đa (CFM)

61.7

Chế độ chuyển mạch

Store and forward

CPU

1.7 GHz ARM CPU on all models

Mật độ cổng GbE

56 (16 2.5GbE host ports + 32 1GbE host ports + 4 10GbE/25GbE ports + 4 port 1GbE/10GbE ports)

Physical Layer

Time domain reflectometry (TDR) for detecting cable breaks and shorts; Auto medium-dependent interface/medium-dependent interface crossover (MDI/MDIX) support; Port speed downshift/setting maximum advertised speed on; 100/1000BASE-T/2.5GBASE-T on EX4100-48MP

Dung lượng chuyển mạch (gói 64 byte)

212 Gbps (unidirectional)/424 Gbps (bidirectional)

Bộ nguồn

Autosensing; 100-120 V/200-240 V; 150 W, 920 W AC AFO, and 150 W AC AFI dual load sharing hot-swappable internal redundant power supplies

Dòng khởi động tối đa

30 amps

Bộ nguồn DC

150 W DC AFO; input voltage range 48-60 V max; dual load-sharing hot-swappable internal redundant power supplies

Số PSU tối thiểu (tải đầy)

1 per switch

Thân máy

17.36 x 1.72 x 13.78 in (44.1 x 4.37 x 35 cm)

Kèm bộ nguồn

17.36 x 1.72 x 15.05 in (44.1 x 4.37 x 38.24 cm)

Chiều cao

1 U

Thân máy (chưa nguồn/quạt)

10.41 lb (4.72 kg)

150 W AC power supply

1.43 lb (0.65 kg)

150 W DC power supply

1.43 lb (0.65 kg)

920 W AC power supply

1.87 lb (0.85 kg)

Module quạt

0.16 lb (0.07 kg)

Nhiệt độ hoạt động

32° to 113° F (0° to 45° C)

Nhiệt độ lưu kho

-40° to 158° F (-40° to 70° C)

Độ cao hoạt động

Up to 5000 ft at 40° C (1828.8 m)

Độ cao khi không hoạt động

Up to 16,000 ft (4877 m)

Độ ẩm khi hoạt động

5% to 90% (noncondensing)

Độ ẩm khi không hoạt động

0% to 90% (noncondensing)

Số quạt thay nóng

2

DRAM

4 GB with Error Correcting Code (ECC) on all models

Bộ nhớ lưu trữ

8 GB on all models

Packets)

315 Mpps

Nền tảng quản trị

Juniper Mist Wired Assurance for campus; Junos Space Network Director for campus; Junos Space Management Applications

Số địa chỉ MAC cho phép

64,000

Số MAC tối đa mỗi hệ thống

64,000

Khung jumbo

9216 bytes

Dải VLAN ID

1 to 4094

Số thực thể VST

253

Số thực thể MST

64

Số thực thể VSTP

253

Số nhóm LAG

128

Số cổng tối đa mỗi LAG

8

Số mục ARP tối đa

32,000

Tuyến IPv4 unicast (phần cứng)

32,650 prefixes; 32,150 host routes

Tuyến IPv4 multicast (phần cứng)

16,100 multicast routes

Giao thức định tuyến

RIPv1/v2, OSPF, BGP, IS-IS

Số VRF-Lite

1000

Số mục IPv6 ND tối đa

16,000

Tuyến IPv6 unicast (phần cứng)

16,200 prefixes; 16,050 host routes

Tuyến IPv6 multicast (phần cứng)

8000 multicast routes

Giao thức định tuyến

RIPng, OSPFv3, IPv6, IS-IS

PACL chiều vào

4092

VACL chiều vào

4092

RACL chiều vào

4092

PACL chiều ra

1022

VLAN-based ACL (VACL) egress

511

RACL chiều ra

1022

Kiểu EAP hỗ trợ (802.1X)

Message Digest 5 (MD5), Transport Layer Security (TLS), Tunneled TLS (TTLS), Protected Extensible Authenticated Protocol (PEAP)

Nonstop routing (NSR)

PIM, OSPF v2 and v3, RIP v2, RIPng, BGP, BGPv6, IS-IS, IGMP v1, v2, v3

Policing chiều vào

1 rate 2 color

Số hàng đợi mỗi cổng

12 (8 unicast + 4 multicast)

Tiêu chí phân loại L2-L4

Interface, MAC address, Ethertype, 802.1p, VLAN, IP address, DSCP/IP precedence, TCP/UDP port numbers, and more

IGMP

v1, v2, v3

Quản trị ngoài băng

Serial; 10/100/1000BASE-T Ethernet

SNMP

v1, v2c, v3

Số cổng đích mirroring

4

Số phiên mirroring tối đa

4

Mirroring tới đích từ xa (L2)

1 destination VLAN

Hiệu quả năng lượng

AT&T TEER (ATIS-06000015.03.2013); ECR 3.0.1; ETSI ES 203 136 V.1.1.1; Verizon TEEER (VZ.TPR.9205)

Môi trường (RoHS)

Reduction of Hazardous Substances (ROHS) 6/6

Viễn thông

CLEI code

Bảo mật

Media Access Control (MAC) limiting (per port and per VLAN); Dynamic Address Resolution Protocol (ARP) dynamic ARP inspection (DAI); IP source guard; Local proxy ARP; Static ARP support; Dynamic Host Configuration Protocol (DHCP) snooping; Captive portal; Persistent MAC address configurations; Distributed denial of service (DDoS) protection (CPU control path flooding protection)

Chuyển mạch lớp 2

Port-based VLAN; Voice VLAN; Physical port redundancy: Redundant trunk group (RTG); Compatible with Per-VLAN Spanning Tree Plus (PVST+); Routed VLAN interface (RVI); Uplink failure detection (UFD); ITU-T G.8032: Ethernet Ring Protection Switching; IEEE 802.1AB: Link Layer Discovery Protocol (LLDP); LLDP-MED with VoIP integration; Default VLAN and multiple VLAN range support; MAC learning deactivate; Persistent MAC learning (sticky MAC); MAC notification; Private VLANs (PVLANs); Explicit congestion notification (ECN); Layer 2 protocol tunneling (L2PT); IEEE 802.1ak: Multiple VLAN Registration Protocol (MVRP); IEEE 802.1p: Class of service (CoS) prioritization; IEEE 802.1Q: VLAN tagging; IEEE 802.1X: Port Access Control; IEEE 802.1ak: Multiple Registration Protocol; IEEE 802.3: 10BASE-T; IEEE 802.3u: 100BASE-T; IEEE 802.3ab: 1000BASE-T; IEEE 802.3z: 1000BASE-X; IEEE 802.3bz: 2.5GBASE-T and 5GBASE-T; IEEE 802.3ae: 10-Gigabit Ethernet; IEEE 802.3by: 25-Gigabit Ethernet; IEEE 802.3af: Power over Ethernet; IEEE 802.3at: Power over Ethernet Plus; IEEE 802.3bt: 90 W Power over Ethernet; IEEE 802.3x: Pause Frames/Flow Control; IEEE 802.3ah: Ethernet in the First Mile

Spanning Tree

IEEE 802.1D: Spanning Tree Protocol; IEEE 802.1s: Multiple Spanning Tree Protocol (MSTP); IEEE 802.1w: Rapid reconfiguration of Spanning Tree Protocol

Gộp liên kết (LAG)

IEEE 802.3ad: Link Aggregation Control Protocol; 802.3ad (LACP) support:; LAG load-sharing algorithm bridged or routed (unicast or multicast) traffic: IP: S/D IP; TCP/UDP: S/D IP, S/D Port; Non-IP: S/D MAC; Tagged ports support in LAG

Lớp 3 – IPv4

Static routing; Routing policy; Bidirectional Forwarding Detection (BFD); L3 redundancy: Virtual Router Redundancy Protocol (VRRP)

Lớp 3 – IPv6

Static routing

Danh sách ACL (firewall filter)

ACL entries (ACE) in hardware per system: ACL counter for denied packets; ACL counter for permitted packets; Ability to add/remove/change ACL entries in middle of list (ACL editing); L2-L4 ACL

Bảo mật truy nhập

802.1X port-based; 802.1X multiple supplicants; 802.1X with VLAN assignment; 802.1X with authentication bypass access (based on host MAC address); 802.1X with VoIP VLAN support; 802.1X dynamic ACL based on RADIUS attributes; MAC authentication (RADIUS); Control plane DoS protection; Radius functionality over IPv6 for authentication, authorization, and accounting (AAA); DHCPv6 snooping; IPv6 neighbor discovery; IPv6 source guard; IPv6 router advertisement (RA) guard; IPv6 Neighbor Discovery Inspection; MACsec

Sẵn sàng cao

Redundant, hot-swappable power supplies; Redundant, field-replaceable, hot-swappable fans; GRES for Layer 2 hitless forwarding and Layer 3 protocols on RE failover; Graceful protocol restart (OSPF, BGP); Layer 2 hitless forwarding on RE failover; Nonstop bridging: LACP, xSTP

Chất lượng dịch vụ (QoS)

L2 QoS; L3 QoS; Scheduling methods (egress): Strict priority (SP), weighted deficit round-robin (WDRR); 802.1p, DiffServ code point (DSCP)/IP precedence trust and marking; Congestion avoidance capabilities: Tail drop, weighted random early detection (WRED)

Multicast

IGMP snooping; Multicast Listener Discovery (MLD) snooping; Protocol Independent Multicast-Sparse Mode (PIM-SM), PIM Source-Specific Mode (PIM-SSM), PIM Dense Mode (PIM-DM)

Quản trị thiết bị

Junos OS CLI; Rescue configuration; Configuration rollback; Image rollback; RMON (RFC2819) groups 1, 2, 3, 9; Remote performance monitoring; Network Time Protocol (NTP); DHCP server; DHCP client and DHCP proxy; DHCP relay and helper; DHCP local server support; RADIUS; TACACS+; SSHv2; Secure copy; HTTP/HTTPs; Domain Name System (DNS) resolver; System logging; Temperature sensor; Configuration backup via FTP/secure copy

Xử lý sự cố

Debugging: CLI via console, Telnet, or SSH; Diagnostics: Show and debug command, statistics; Traffic mirroring (port); Traffic mirroring (VLAN); IP tools: Extended ping and trace; Juniper Networks commit and rollback

Giám sát lưu lượng

ACL-based mirroring; LAG port monitoring; Multiple destination ports monitored to 1 mirror (N:1)

Tương thích điện từ (EMC)

FCC 47 CFR Part 15; ICES-003 / ICES-GEN; EN 300 386 V1.6.1; EN 300 386 V2.1.1; EN 55032; CISPR 32; EN 55024; CISPR 24; EN 55035; CISPR 35; IEC/EN 61000 Series; AS/NZS CISPR 32; VCCI-CISPR 32; BSMI CNS 13438; KN 32 and KN 35; KN 61000 Series; TEC/SD/DD/EMC-221/05/OCT-16; TCVN 7189; TCVN 7317

An toàn (thân máy và quang)

CAN/CSA-C22.2 No. 62368-1 and 60950-1; UL 62368-1 and 60950-1; IEC 62368-1 and 60950-1 (All country deviations): CB Scheme report; IEC 62368-3 for USB and PoE: CB Scheme report; CFR, Title 21, Chapter 1, Subchapter J, Part 1040; REDR c 1370 OR CAN/CSA-E 60825-1-Part 1; IEC 60825-1; IEC 60825-2

EX4100-48MP

36.8

54.3

EX4100-48MP

Juniper EX4100-48MP – Multigigabit 48 port, PoE++ (up to 90 W) switch with 16x100 MB/1GbE/2.5GbE + 32x10 MB/100 MB/1GbE, 4x10GbE uplinks, 4x25GbE stacking/uplink ports, MACsec AES256, redundant fans, 1x JPSU-920-AC-AFO included with Standard SW, optics sold separately.

S-EX-A-C3-P

Perpetual Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), Perpetual license for EX4100 48-port switches

S-EX-P-C3-P

Perpetual Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), Perpetual license for EX4100 48-port switches

S-EX-MACSEC-C3-P

Perpetual Licenses – Software, EX Series MACsec license, Class 3 (48 ports), Perpetual license for EX4100 48-port switches

S-EX4100-FBT-P

Perpetual Licenses – Software, EX Series Flow Based Telemetry License. Perpetual license for all EX4100 switches.

S-EX-A-C3-1

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches, 1 year

S-EX-A-C3-3

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches, 3 year

S-EX-A-C3-5

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches, 5 year

S-EX-P-C3-1

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches, 1 year

S-EX-P-C3-3

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches, 3 year

S-EX-P-C3-5

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches, 5 year

S-EX-A-C3-1-COR

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC CORE support, 1 year

S-EX-A-C3-3-COR

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC CORE support, 3 year

S-EX-A-C3-5-COR

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC CORE support, 5 year

S-EX-P-C3-1-COR

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC CORE support, 1 year

S-EX-P-C3-3-COR

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC CORE support, 3 year

S-EX-P-C3-5-COR

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC CORE support, 5 year

S-EX-A-C3-1-ND

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC NEXT DAY support, 1 year

S-EX-A-C3-3-ND

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC NEXT DAY support, 3 year

S-EX-A-C3-5-ND

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC NEXT DAY support, 5 year

S-EX-P-C3-1-ND

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC NEXT DAY support, 1 year

S-EX-P-C3-3-ND

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC NEXT DAY support, 3 year

S-EX-P-C3-5-ND

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC NEXT DAY support, 5 year

S-EX-A-C3-1-SD

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC SAME DAY support, 1 year

S-EX-A-C3-3-SD

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC SAME DAY support, 3 year

S-EX-A-C3-5-SD

Subscription Licenses – Software, EX Series Advanced license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC SAME DAY support, 5 year

S-EX-P-C3-1-SD

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC SAME DAY support, 1 year

S-EX-P-C3-3-SD

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC SAME DAY support, 3 year

S-EX-P-C3-5-SD

Subscription Licenses – Software, EX Series Premium license, Class 3 (32 or 48 ports), includes Juniper Mist Wired Assurance and VNA subscription for EX Series 48-port switches with SVC SAME DAY support, 5 year

JPSU-150-AC-AFO

Power Supplies – EX Series 150 W AC power supply (power cord needs to be ordered separately) (front-to-back airflow)

JPSU-150-AC-AFI

Power Supplies – EX Series 150 W AC power supply (power cord needs to be ordered separately) (back-to-front airflow)

JPSU-150-DC-AFO

Power Supplies – EX Series 150 W DC power supply (power cord needs to be ordered separately) (front-to-back airflow)

JPSU-920-AC-AFO

Power Supplies – EX Series 920 W DC power supply (power cord needs to be ordered separately) (front-to-back airflow)

EX4100-FAN-AFO

Fans – Spare fan with front-to-back airflow

EX4100-FAN-AFI

Fans – Spare fan with back-to-front airflow

EX-4PST-RMK

Mounting Options – Adjustable 4-post rack-mount kit for EX4100

EX-WMK

Mounting Options – Wall-mount kit for EX4100

EX-RMK

Mounting Options – EX Series Rack Mount Kit
